Feature
- 1/3” 960H SONY Super HAD II Sensor
- 700 TVL Resolution / 3.6mm Lens
- AISI 316 Stainless Steel Housing
- 15 Piece White LED Array
- Remotely Adjustable LED Control
- Corrosion / Bacteria Resistant
- Smart 3D-DNR / SENS-UP x8
- SS316 Bracket Included
Specifications
| SPECIFICATIONS | CC06-HB36F |
| Image Sensor | 1/3″ 960H SONY Super HAD II CCD |
| Effective Pixels | 976 x 494 |
| Resolution | 700 TV Lines |
| Lens | 3.6mm Fixed Lens |
| Scanning System | 2:1 Interlaced |
| Sync System | Internal |
| S/N Ratio | More than 52dB |
| Video Output | 1.0 Vp-p Composite Video, 75 Ohms |
| Illumination | 0.1 Lux at F1.2 / 0.001 Lux with SENS-UP On |
| LED’s | 15 Piece White LED Array, Remotely Adjustable |
| Electronic Shutter | 1/60~1/100,000 Sec. |
| SENS-UP | x8, Default |
| Gain Control | Automatic |
| Housing | AISI SS316 / IP68 |
| Bracket | Included |
| Power | 12V DC |
| Power Consumption | Max. 1.0w (160mA) |
| Operating Humidity | 30% ~ 90% |
| Dimensions | 49mm x 114mm / 1.93″ x 4.49″ |
| operating Temperature | 14º~122º F (-10º~50º C) |
| Weight | 600g / 1.32 Lbs. |
